15hp Frequency Conversion Industrial Screw Compressor Customized
Color
15hp frequency conversion industrial screw air compressorare with Gemerny made belts, by which driving efficiency can reach
99%, besides, also has special BCA automatic fore adjustment
device, to ensure constant transmission efficiency and excellent
driving system reliability.
screw air compressor features:
1, perfect performance
2, microcomputer controller
3, blet screw compressor
4, restart function when power off
5, VSD energy saving
Screw Compressor Technical Parameters
| DHH | Air flow Capacity(m3/min)/cfm | Power | Noise | Diameter | Dimension | Weight |
| 0.7Mpa | 0.8Mpa | 1.0Mpa | 1.25Mpa | KW/HP | DB(A) | INCH | W×D×H mm | Kg |
| MODEL | m3/min | cfm | m3/min | cfm | m3/min | cfm | m3/min | cfm | | | | | | |
| DB-7.5A | 0.91 | 32.1 | 0.84 | 29.6 | 0.75 | 26.5 | 0.63 | 22.2 | 5.5/7.5 | 65 | G3/4'' | 780×680×800 | 300 |
| DB-10A | 1.3 | 45.9 | 1.2 | 42.4 | 1.0 | 35.3 | 0.84 | 29.6 | 7.5/10 | 65 | G3/4'' | 780×680×800 | 320 |
| DB-15A | 1.7 | 60 | 1.6 | 56.5 | 1.4 | 49.4 | 1.2 | 42.4 | 11/15 | 65 | G3/4'' | 1100×800×980 | 400 |
| DB-20A | 2.4 | 84.8 | 2.3 | 81.2 | 2.0 | 70.6 | 1.6 | 56.5 | 15/20 | 68 | G3/4'' | 1100×800×980 | 430 |
| DB-25A | 3.0 | 105.9 | 2.9 | 102.4 | 2.7 | 95.3 | 2.3 | 81.2 | 18.5/25 | 68 | G1'' | 1250×870×1180 | 590 |
| DB-30A | 3.7 | 130.7 | 3.6 | 127.1 | 3.2 | 113 | 2.8 | 98.9 | 22/30 | 68 | G1'' | 1250×870×1180 | 650 |
| DB-40A | 5.2 | 183.6 | 5.0 | 176.6 | 4.5 | 158.9 | 3.8 | 134.2 | 30/40 | 69 | G1'' | 1250×870×1180 | 750 |
| DB-50A | 6.5 | 229.5 | 6.2 | 219 | 5.6 | 197.8 | 4.9 | 173 | 37/50 | 69 | G11/2'' | 1540×950×1310 | 880 |
| DB-60A | 8.0 | 282.5 | 7.3 | 257.8 | 7.0 | 247.2 | 5.9 | 208.4 | 45/60 | 70 | G11/2'' | 1540×950×1310 | 1000 |
| DB-75A/W | 10.1 | 356.7 | 9.5 | 335.5 | 8.7 | 307.2 | 7.8 | 275.5 | 55/75 | 70 | G2'' | 1600×1150×1420 | 1500 |
| DBY-7.5A | 0.91 | 32.1 | 0.84 | 29.6 | 0.75 | 26.5 | 0.63 | 22.2 | 5.5/7.5 | 65 | G3/4'' | 1230×600×1262 | 375 |
| DBY-10A | 1.3 | 45.9 | 1.2 | 42.4 | 1.0 | 35.3 | 0.84 | 29.6 | 7.5/10 | 65 | G3/4'' | 1230×600×1262 | 395 |
| DBY-15A | 1.7 | 60 | 1.6 | 56.5 | 1,4 | 49.4 | 1.2 | 42.4 | 11/15 | 65 | G1'' | 1470×800×1615 | 500 |
| DBY-20A | 2.4 | 84.8 | 2.3 | 81.2 | 2.0 | 70.6 | 1.6 | 56.5 | 15/20 | 68 | G1'' | 1470×800×1615 | 530 |
A represents air-cooling type, W represents water-cooling type;
Working environment temperature: - 5 °C ~ 45 °C;
The exhaust temperature is less than environment temperature about
+ 10 °C ~ 15 °C.
Driving mode: belt transmission;
Startup mode: direct start under 11KW, and Y-Δ start above 11KW;
Work power: 380V / 50HZ, 460V / 230V / 6KV and 10KV voltages can be
made for customers;
F.A.D volume flow test is according to ASMC PTC9 or ISO1217
standard (GB/T3853).
Our Service
1. All the equipment warranty period of two years.
2 after-sales service
In the warranty period, Free Technical Support, any questions on
using machines, our engineers will provide you with professional
technical support by mail, remote monitor and control, fax, or
phone in 24hrs.If it is necessary, engineer would be dispatched to
customer site. During the warranty period, all spare parts is free
provided. During the warranty period, spare parts providing only
charge cost price.
3. the seller provides the buyer with a set of tools including
toolbox.
Any Problem please contact our Allepack sales team!
